Description
NDR-75-48 Ernitec DC Single Output Industrial DIN Rail Power Supply Units – 24V
Compact Size with more Practicability and Convenience
Ernitec has released a series of DC single output industrial DIN rail power supply units to make sure that industrial Ethernet devices, specially designed for the harsh working environment, get DC voltage power easily.
Ernitec DC single output industrial DIN rail power supply units accept universal 100-240V AC input voltage and provide 48V DC power output with various watt values.
Its power supply units are designed in compact size and can be installed on DIN rail TS-35 / 7.5 or 15. It is an ideal and convenient DC power feeding solution for Industrial equipment under heavy Industrial environments.
Stable Performance under Difficult Environments
Ernitec DC single output industrial DIN rail power supply units come with such protection features as short circuit, overload, over voltage and over temperature for the stable operation of industrial Ethernet equipment.
It uses the free air convection cooling system to prevent operating temperature from rising.
Being able to operate under the temperature range from -20 to 70 degrees C (maximum), the DC single output industrial DIN rail power supply units can be placed in almost any difficult environments.
Design
Cooling type
Passive
Product colour
Blue, Grey
Operational conditions
Operating relative humidity (H-H)
20 – 95 %
Operating temperature (T-T)
-20 – 70 °C
Storage relative humidity (H-H)
10 – 95 %
Storage temperature (T-T)
-40 – 85 °C
Performance
Certification
Ul508, TUV EN60950-1
Safety
Ul508, TUV EN60950-1
Power
AC input frequency
50 – 60 Hz
AC input voltage
100 – 240 V
Input current
1.45 A
Power protection features
Over voltage, Overheating, Overload, Short circuit
Total power
75 W
